Timing Belt Modules VBF10

Motor power: 200W Repeatability: ±0.05mm Lead: 45mm Maximum speed: 2000mm/s Horizontal load: 15kg

Category:

VBF Series (Timming Belt Linear Stage, General Environment)

E-mail

Telephone

Product Details
Application Cases
Related downloads

Ⅰ. Product Overview
The WILLOBO VBF10 Timing Belt Module is a high-speed, high-efficiency linear motion platform designed for applications that require long stroke, stable transmission, and precise repeatability.
It adopts a timing belt + precision linear guide structure, enabling smooth and accurate motion with minimal noise and vibration.
Thanks to its compact body and modular interface, the VBF10 is easy to integrate into various automation equipment such as pick-and-place machines, conveyors, and inspection systems, offering a balance of speed, precision, and reliability.
Ⅱ. Technical Features
High-speed timing belt transmission with low friction and high efficiency
Long stroke capability with consistent motion stability
Rigid aluminum profile body ensures smooth operation and accuracy
Compact design suitable for space-constrained installations
Optional servo motor compatibility for closed-loop control
Quiet operation and low maintenance requirements
Supports horizontal, vertical, and inverted mounting orientations
Ⅲ. Product Advantages
Fast, smooth, and stable linear motion
High repeatability and reliable accuracy
Lightweight design reduces inertia for dynamic applications
Low maintenance with minimal lubrication needs
Modular compatibility supports multi-axis linkage or combination setups
Cost-effective solution for long-travel linear positioning
Ⅳ. Application Fields
The VBF10 Timing Belt Module is ideal for a wide range of industrial automation systems, including:
High-speed assembly and transfer lines
Laser cutting, engraving, and marking systems
Packaging and labeling machinery
Electronic component testing and placement platforms
Logistics and material handling automation
Multi-axis robotic systems and gantry platforms
With its balance of speed, stability, and precision, the VBF10 provides an efficient motion foundation for modern automation lines.
Ⅴ. Model Selection & Customization
WILLOBO provides a flexible customization service for the VBF10 series to meet various industrial demands:
Adjustable stroke length and payload capacity
Compatible with multiple motor brands and flange standards
Optional cover plates for semi-sealed environments
Multi-axis modular integration (X/Y/Z configurations)
Custom mounting holes and interface directions
2D/3D design drawings and performance data available upon request
Ⅵ. Installation & Maintenance
Ensure the installation base is flat, rigid, and free from vibration
Maintain appropriate belt tension to prevent slip or backlash
Keep the belt and guide clean from dust and debris
Lubricate guide rails periodically for optimal smoothness
Perform belt tension inspection every 6 months
Avoid continuous operation under high humidity or high temperature
Ⅶ. Related Products
VGTB8 Timing Belt Module
VETB22 Semi-Sealed Belt Module
VGTH12 Ball Screw Linear Module
VGTY12 Electric Cylinder Module
VL14 Linear Motor Module
Ⅷ. More Information
For detailed specifications, motion curves, or CAD drawings of the VBF10 Timing Belt Module, please visit www.w-robot.com or contact the WILLOBO technical team for customized engineering support.
The VBF10 delivers a perfect blend of speed, accuracy, and versatility, empowering next-generation automation systems with efficient linear motion solutions.

Factory Workshop

Listed below are answers to our most commonly asked questions. Don't see your question?Contact our customer service team. We would be glad to assist you.

FAQ

Listed below are answers to our most commonly asked questions. Don't see your question?Contact our customer service team. We would be glad to assist you.

What are the future development trends of linear modules and linear motors?

In the future, linear modules and linear motors will develop towards higher precision, higher speed, smaller size, intelligence, and integration with other advanced technologies (such as artificial intelligence and the Internet of Things).

What parameters need to be provided for customized linear motors?

It is necessary to provide detailed parameters such as load weight, stroke, speed, acceleration, accuracy requirements, installation method, and operating environment so that the manufacturer can design and manufacture a linear motor that meets the requirements.

How long is the customization cycle of linear modules?

The customization cycle depends on the complexity of the customization and the manufacturer's production capacity, generally about 1-4 weeks. The specific time can be determined by communicating with the manufacturer.

Can linear motors be upgraded?

The performance of linear motors can be improved by upgrading them with high-performance drives, optimizing control system parameters, and improving heat dissipation structures.

Is it easy to upgrade the linear module?

It is relatively easy to upgrade the motor, control system, guide rail and other components of the linear module according to actual needs to improve its performance and accuracy.

What is the after-sales maintenance service of linear motors?

Regular manufacturers usually provide comprehensive after-sales maintenance services, including fault diagnosis, maintenance guidance, parts replacement, etc., but the response speed and quality of after-sales maintenance services may vary from manufacturer to manufacturer.

What is the warranty period for linear modules?

The warranty period of linear modules from different manufacturers varies, generally around 1-2 years. The specific warranty period can be confirmed with the manufacturer at the time of purchase.

What should we pay attention to when integrating linear motors with other equipment?

Attention should be paid to issues such as interface compatibility, signal matching, control logic coordination, and installation space and layout between devices to ensure that the devices can work together.

Can the linear module be integrated with other equipment?

Absolutely. Linear modules can be integrated with other devices such as robots, sensors, and vision systems to build more complex and intelligent automated production lines.

What kind of control system do linear motors require?

Linear motors typically require a high-performance motion control system that can achieve precise position control, speed control, and thrust control, such as a dedicated linear motor drive with a motion control card or a high-end PLC.
