Linear Motor Modules VGL6

Total length L = Effective stroke + 164mm Reference origin position: 82mm Mechanical limit: 15.5mm Mounting holes: 4 x M4, 8.0mm depth Critical positioning dimension: 51±0.02mm

Category:

VGL Series (Fully Enclosed-Linear Motor Actuator)

E-mail

Telephone

Product Details
Application Cases
Related downloads

Linear Motor Module – VGL6
High Speed · High Precision · Compact Linear Motion Platform
Ⅰ. Product Overview
The VGL6 Linear Motor Module from W‑ROBOT is a high-performance direct-drive linear motion system designed for automation equipment and precision manufacturing. Incorporating a linear motor drive rather than belt or screw transmission, the VGL6 eliminates mechanical backlash and delivers true direct-drive linear motion.
This module features a compact and low-profile design, with integrated linear guide rail and high-rigidity structure, enabling ultra-high speed, smooth travel, and excellent positioning repeatability. It is ideal for applications in electronics assembly, optical inspection, precision measurement and other high-end automation fields.
Ⅱ. Technical Features
Linear motor direct drive — no mechanical transmission means minimal backlash, high responsiveness.
High speed & acceleration — designed for rapid traverse and high cycle automation.
Compact & low profile — allows integration into space-constrained systems without compromising performance.
High rigidity & stability — structural design ensures minimal deflection under dynamic loads.
Quiet operation — linear motor and guide combination produce low-noise, smooth motion.
Easy integration — standardized mounting interfaces, sensor grooves, CAD models available.
High precision — suitable for applications requiring repeatability and fine positioning.
Ⅲ. Application Fields
The VGL6 module is well suited for automation systems such as:
High-speed pick-and-place and component transfer in electronics manufacturing
Optical inspection and measurement machines requiring rapid scan or traverse
Laboratory automation and medical device automation where smooth, fast motion is required
CNC auxiliary axes or engraving systems requiring high speed and precision
Lightweight robotic linear axes where compact size and high performance matter
Ⅳ. Model Selection & Customization
W-ROBOT offers full customization for the VGL/VL Series modules:
Adjustable stroke length, speed and acceleration to match your design needs
Motor mounting options (servo, stepper, integrated linear motor) and flange compatibility
Custom guide rail accuracy grades and surface treatments for demanding precision
Multi-axis configuration support (X, Y, Z or Cartesian layout)
2D/3D CAD drawings, full technical documentation, and integration support available
Ⅴ. Product Advantages
Direct-drive linear motor gives zero transmission backlash and high dynamic response
Compact structure with high performance in small footprint
Low maintenance, fewer mechanical wear parts versus belt or screw systems
Smooth, high-precision motion suitable for sensitive automation tasks
Flexible for integration into modern smart manufacturing systems
Excellent cost-to-performance for high-speed precision applications
Ⅵ. Installation & Maintenance
Ensure installation base is flat, rigid, and properly supported.
Align the guide rails and motor mounting precisely to maintain high accuracy.
Keep rails and carriage clean; contamination may degrade performance.
Conduct periodic inspection of repeatability and calibration (every 6–12 months).
Avoid high humidity, strong magnetic fields, or extreme thermal environments.
Tighten all mounting connections to specified torque; consult CAD or manual for details.
Ⅶ. Learn More
For full technical specifications, CAD models, performance curves of the VGL6 Linear Motor Module, please visit: www.w-robot.com or contact W-ROBOT’s technical team for selection support and integration consulting.
