Linear Rotary Actuator – ZR-DS10-50

Z-Axis Stroke ；40mm Rated/Peak Thrust ；30/60N Max Payload ；2700g

Category:

ZR Series ( Linear Rotary Actuator )

E-mail

Telephone

Product Details
Application Cases
Related downloads

1. Product Overview
The ZR-DS10-50 Linear Rotary Actuator from W-ROBOT integrates linear motion and rotary control in a compact, high-performance dual-axis design.
It features a precision ball screw drive combined with a servo-controlled rotary axis, delivering simultaneous or independent control of linear displacement and rotational movement.
Designed for applications such as screw fastening, insertion, pressing, and assembly automation, the ZR-DS10-50 offers high torque, smooth operation, and micron-level accuracy, making it ideal for intelligent manufacturing and robotics.
2. Technical Features
Integrated Linear + Rotary Drive for synchronized or independent motion control.
High Torque Rotary Axis — suitable for fastening, turning, and clamping operations.
Precision Ball Screw Linear Transmission with excellent rigidity and minimal backlash.
Closed-Loop Servo Control ensures precise position, angle, and torque regulation.
Compact Structure for easy integration into multi-axis or robotic systems.
Optional Hollow Shaft for air or cable routing.
Modular Interface Design — compatible with industrial controllers and motion platforms.
Low Noise, Low Maintenance, Long Service Life.
3. Application Fields
The ZR-DS10-50 is widely used in:
Automatic screw-driving systems
Precision component assembly equipment
Pick-and-place and testing machines
Semiconductor handling and automation lines
Optical alignment and measurement systems
Medical and laboratory automation platforms
Its ability to deliver simultaneous linear and rotary motion helps simplify mechanical systems, reduce component count, and enhance overall efficiency.
4. Model Selection & Customization
W-ROBOT offers a range of customization and configuration options for the ZR-DS10-50:
Adjustable linear stroke, rotation range, and torque level
Multiple servo interface options (EtherCAT, CANopen, pulse signal, etc.)
Custom mounting flanges and couplers for various tools and end-effectors
Different encoder resolutions and feedback systems
Available 2D/3D CAD files, datasheets, and installation drawings
5. Technical Support & Documentation
For comprehensive specifications — including torque curves, motor parameters, and assembly guidance — please contact the W-ROBOT technical support team.
Our engineers provide professional assistance for model selection, integration, and servo control setup.
6. Product Advantages
Combines linear and rotary motion in one compact actuator
High torque and long linear stroke (up to 50 mm)
Smooth, low-vibration operation
Precise and repeatable motion performance
Simplified mechanical structure, easy wiring
High rigidity, suitable for industrial-grade automation
Excellent reliability and long service life
7. Installation & Maintenance
Install on a rigid, level mounting surface to ensure precision.
Keep linear guideways and screw mechanisms clean.
Check for alignment of ball screw and rotary shaft before operation.
Avoid external shock, side loads, and excessive torque.
Regularly inspect encoder and servo system connections.
Perform preventive maintenance every 6–12 months for optimal reliability.
8. Learn More & Related Products
Explore more dual-axis and linear motion systems from W-ROBOT:
Linear Rotary Actuator – ZR-DS8-32
Ball Screw Module – VGTH5
Linear Motor Module – VL17
Electric Gripper – EPGC Series
For more technical information and CAD downloads, please visit www.w-robot.com.
