VDX50 Direct Drive Rotary Motor

Motor width: 120mm Motor height: 60mm Mounting hole spacing: 90mm (center distance) Mover length: Standard length 200mm Stator cross-section: 50×60mm rectangular cross-section

Category:

VDX Series (Coreless Linear Motor)

E-mail

Telephone

Product Details
Application Cases
Related downloads

VDX50 Direct Drive Rotary Motor
High Torque · Zero Backlash · Smooth Precision Motion
Ⅰ. Product Overview
The VDX50 Direct Drive Rotary Motor from W-Robot is a high-performance torque motor designed for advanced automation, semiconductor, and robotics applications that demand exceptional precision and stability. Featuring a direct drive structure without mechanical transmission, the VDX50 delivers zero backlash, ultra-smooth rotation, and instant torque response — enabling precise control in high-end positioning and motion systems.
Its compact and rigid frame, combined with a low-profile and high-torque design, makes it ideal for space-constrained yet performance-critical applications such as rotary indexing tables, robot joints, optical positioning stages, and semiconductor wafer handling systems.
Ⅱ. Technical Features
Direct Drive Design – eliminates mechanical gears, ensuring zero backlash and high accuracy.
High Torque Density – compact size yet delivers strong continuous torque output.
Low Cogging & Smooth Rotation – ideal for scanning, inspection, and fine positioning.
Hollow Shaft Option – allows cable, vacuum, or pneumatic passage through the motor center.
High Dynamic Response – fast acceleration and deceleration with minimal settling time.
Maintenance-Free – no transmission components, ensuring long service life and stable operation.
Compatible with High-Resolution Encoders – enables sub-arcsecond positioning accuracy.
Ⅲ. Application Fields
The VDX50 motor is widely used in:
Semiconductor wafer transfer and inspection systems
High-precision optical instruments
Robotic arm rotary joints and end-effectors
CNC rotary positioning and indexing tables
Laser cutting, engraving, and metrology equipment
Aerospace testing and motion simulation systems
With its direct-drive structure and ultra-smooth motion, VDX50 provides engineers with an advanced platform for precision automation and motion control.
Ⅳ. Model Selection & Customization
W-Robot provides flexible customization for the VDX Series, including:
Torque and speed tuning for specific load profiles
Custom shaft and flange interfaces
Integration with optical or magnetic encoders
Optional hollow-shaft design for tool or cable routing
Tailored cooling and thermal control options
Multi-axis and rotary-linear combined configurations
For detailed specifications and CAD models, visit www.w-robot.com.
Ⅴ. Product Advantages
High torque output with compact footprint
Zero mechanical backlash for precise motion control
Ultra-smooth and quiet rotation
Long lifespan and no lubrication required
Excellent repeatability for high-end automation
Supports integration with multiple servo drive systems
Ⅵ. Installation & Maintenance
Ensure the mounting surface is flat and rigid
Avoid impact or radial overload during installation
Use appropriate torque for all fasteners
Keep encoder and feedback cables shielded and secure
Maintain clean, dust-free operating environment
Perform periodic accuracy checks for optimal performance
Ⅶ. Learn More
Explore more at www.w-robot.com:
Download CAD models and full product catalog
Read: “Why Direct Drive Motors Lead the Future of Precision Automation”
Contact the W-Robot engineering team for system integration support
