Electric cylinder module - VGTYD4

Maximum Stroke ；500mm Maximum Payload ；25Kg Body Width ；44mm

Category:

VGTYD Series（Exquisite Structure、 High Thrust）

E-mail

Telephone

Product Details
Application Cases
Related downloads

Embedded Electric Cylinder Module – VGTYD4
Compact Design · Precise Force Control · Integrated Linear Motion Solution
1. Product Overview
The Willbot VGTYD4 Embedded Electric Cylinder Module is a compact and integrated linear actuator designed for precise, stable, and clean motion control.
It adopts an embedded motor and ball screw drive structure, combining the features of a traditional cylinder and servo actuator into one compact system.
With excellent force control, positioning accuracy, and space-saving design, VGTYD4 is widely used in applications such as precision assembly, medical automation, micro-mechanical devices, and inspection systems.
It delivers consistent linear motion performance even under high-frequency and long-term operations.
2. Technical Features
Embedded motor structure, minimizing installation space
High-precision ball screw transmission for stable and smooth motion
Integrated linear guide rail ensures rigidity and load capacity
Precise force and position control through servo drive feedback
Compact body, ideal for limited-space automation equipment
Low noise, low friction, maintenance-free design
Supports horizontal, vertical, or inclined installation
Optional motor mounting orientation and sensor integration
3. Application Fields
The VGTYD4 Electric Cylinder Module is ideal for:
Precision assembly and positioning platforms
Medical and laboratory automation systems
Optical component alignment and micro-adjustment mechanisms
Industrial testing and inspection devices
Robotics and multi-axis collaborative equipment
Semiconductor and cleanroom applications
Its embedded structure and high precision make it a preferred choice for miniaturized and high-accuracy motion systems.
4. Model Selection & Customization
Willbot offers flexible customization for the VGTYD series, including:
Custom stroke length, speed, and thrust levels
Compatible with major servo motor brands and drives
Optional feedback sensors and home/limit switches
Support for horizontal, vertical, and inverted mounting
Available 2D/3D CAD models and electrical interface drawings
Integration-ready design for multi-axis configurations
5. Product Advantages
Compact and lightweight, perfect for embedded motion platforms
High efficiency with accurate force and position control
Maintenance-free operation with long service life
Easy to install and integrate into existing automation systems
Stable operation with minimal vibration and noise
Ideal for clean, precise, and repetitive motion applications
The VGTYD4 offers a perfect balance between precision, compactness, and reliability, redefining micro-motion control in modern automation.
6. Installation & Maintenance
Ensure a flat, rigid mounting surface before installation
Align axis precisely to prevent offset and mechanical strain
Keep ball screw and guide rail surfaces clean and dust-free
Factory-prelubricated; periodic relubrication recommended based on duty cycle
Avoid exposure to excessive vibration, oil mist, or moisture
Perform precision checks every 6–12 months for optimal performance
7. More Information
For detailed technical data, 3D models, and application guidance,
please contact Willbot’s technical support team.
We provide professional assistance in model selection, integration, and motion system optimization.
