DDRE-224-062 Direct Drive Rotary Motor

Motor Size ；224(D)*062(H)mm Cont Torque ；35N.m Peak Torque ；105N.m Cont/Peak CUR ；2.2/6.6A-rms

Category:

DDRE Series (External Rotor Motor)

E-mail

Telephone

Product Details
Application Cases
Related downloads

DDRE-224-062 Direct Drive Rotary Motor
High Torque · Precision Motion · Zero Backlash
Ⅰ. Product Overview
The DDRE-224-062 direct drive rotary motor from W-Robot is a high-torque, precision servo solution engineered for advanced automation, semiconductor, and robotic applications. With an outer diameter of 224 mm and a stator height of 62 mm, this model provides excellent torque density and rotational accuracy while maintaining a compact form factor.
Its direct-drive architecture eliminates gear transmission, ensuring zero backlash, low noise, and outstanding smoothness in motion control. Designed for high-speed and high-accuracy positioning systems, DDRE-224-062 delivers consistent and stable performance under continuous operation — ideal for applications requiring reliability and precision.
Ⅱ. Technical Features
Direct-drive design: Provides zero mechanical backlash and excellent torque transmission efficiency.
High torque output: Capable of handling large inertial loads with rapid acceleration and deceleration.
Large hollow shaft: Enables convenient cable routing, pneumatic, or vacuum line passage for system integration.
Low noise and vibration: Smooth, stable operation suitable for high-precision environments.
High-resolution feedback compatibility: Supports absolute or incremental encoders for ultra-precise motion.
Maintenance-free structure: No belts or gears; minimal wear and long service life.
Customizable mechanical interface: Flexible mounting configurations to suit various installation needs.
Ⅲ. Application Fields
The DDRE-224-062 excels in high-performance systems requiring accuracy, torque, and responsiveness, including:
Semiconductor wafer handling and indexing platforms
Precision assembly and inspection equipment
CNC rotary axes and high-speed positioning tables
Robotics rotary joints and end-effectors
Optical alignment and laser processing systems
Measurement and laboratory automation systems
Its combination of torque density, precision, and direct control makes it an ideal component for the next generation of intelligent automation equipment.
Ⅳ. Model Selection & Customization
W-Robot provides comprehensive customization options for the DDRE Series, enabling perfect alignment with your design and performance needs:
Optimized torque and speed tuning for application-specific loads
Encoder options: optical, magnetic, or absolute types
Cooling methods: natural, forced air, or liquid cooling
Hollow shaft and flange interface customization
Multi-axis configurations (θ-Z or rotary stages)
CAD models (2D/3D) and full technical documentation available upon request
Ⅴ. Product Advantages
Zero backlash for ultra-precise motion control
Compact design with high torque density
Quiet and smooth operation – ideal for cleanroom or precision environments
No mechanical maintenance required
High reliability and stability under continuous operation
Easy system integration with modular compatibility
Ⅵ. Installation & Maintenance
Ensure the mounting base is flat, rigid, and vibration-free before installation.
Align encoder and shaft accurately for stable feedback performance.
Keep cables and connectors properly shielded and routed through the hollow shaft.
Avoid high humidity, dust, or magnetic interference environments.
Periodically inspect mounting screws, connectors, and encoder alignment.
Follow manufacturer’s torque specifications for installation.
Ⅶ. Learn More
Explore more with W-Robot:
Visit our product catalog and CAD downloads at www.w-robot.com
Read our technical article: “The Advantages of Direct Drive Rotary Motors in Precision Automation”
Contact W-Robot’s engineering team for customized selection, simulation, and integration support
