Direct Drive Rotary Motor-DDRE-224-042

Motor Size ；224(D)*042(H)mm Cont Torque ；14.1N.m Peak Torque ；42.2N.m Cont/Peak CUR ；2.2/6.6A-rms

Category:

DDRE Series (External Rotor Motor)

E-mail

Telephone

Product Details
Application Cases
Related downloads

DDRE-224-042 Direct Drive Rotary Motor
High Torque · High Precision · Hollow Shaft Design
Ⅰ. Product Overview
The DDRE-224-042 direct drive rotary motor from W-Robot is a high-precision, large-aperture torque motor engineered for demanding automation and motion control applications.
Utilizing a frameless, direct-drive design, it provides smooth rotation, zero backlash, and superior torque density without the need for mechanical transmission components such as gears or belts.
With its 224 mm outer diameter and 42 mm stator height, the DDRE-224-042 delivers both compactness and performance, making it ideal for semiconductor handling systems, precision rotary tables, measurement instruments, and robotics requiring accurate and dynamic rotary motion.
Ⅱ. Technical Features
Direct-drive structure – eliminates mechanical transmission errors, ensuring ultra-smooth and precise motion.
High torque density – compact size with powerful continuous torque output.
Hollow shaft design – enables easy cable, air, or fluid passage for integrated system layouts.
High-resolution feedback – supports optical or magnetic encoders for sub-arcsecond positioning.
Low vibration & noise – provides stable motion for inspection and metrology applications.
Maintenance-free operation – no lubrication, gears, or belts required for long service life.
Flexible installation – adaptable for both vertical and horizontal mounting orientations.
Ⅲ. Application Fields
The DDRE-224-042 is particularly suitable for precision applications such as:
Semiconductor wafer handling and transfer systems
Optical inspection and metrology equipment
High-precision CNC rotary tables
Robotics joint actuation and indexing platforms
Tool changers and automation assembly turntables
Aerospace and laboratory testing instruments
Its direct-drive architecture allows for ultra-fast response and highly repeatable motion accuracy, setting a new benchmark for industrial rotary motion systems.
Ⅳ. Model Selection & Customization
W-Robot provides complete customization options to match diverse integration requirements:
Torque and speed tuning for specific motion profiles
Encoder compatibility (optical, magnetic, or absolute encoders)
Cooling options – natural cooling or forced air/liquid cooling
Hollow shaft dimension customization
Motor flange design adaptation for system fit
Multiple motor sizes and torque levels in the DDRE Series
Comprehensive 2D/3D CAD models, wiring diagrams, and performance data sheets are available upon request.
Ⅴ. Product Advantages
Zero-backlash and high precision due to direct-drive construction
Compact yet powerful torque output suitable for demanding automation
Maintenance-free, reducing total cost of ownership
Smooth and quiet operation, ideal for precision machinery
Modular and flexible integration options
High stability and repeatability over long-term operation
Ⅵ. Installation & Maintenance
Ensure rigid and flat mounting surfaces to minimize vibration and misalignment.
Use compatible high-resolution encoders for optimal feedback performance.
Maintain proper cable routing through the hollow shaft to avoid interference.
Avoid high-humidity or high-temperature environments.
Regularly inspect electrical connections and torque mounting bolts to specified values.
Follow recommended alignment procedures during assembly for accuracy.
Ⅶ. Learn More
Explore more with W-Robot:
Visit the full product line at www.w-robot.com
Technical resources: “How Direct Drive Motors Improve Motion System Accuracy”
Contact W-Robot’s engineering team for application support and integration consultation
🔗 Related Products
Ball Screw Linear Actuator – QF6N
Ball Screw Module – VGTH5
Linear Motor Module – VL17
Electric Gripper – EPGC Series
